GIGABYTE Z890 UD WIFI6E Intel Core Ultra (Series 2) LGA 1851 Motherboard, ATX, DDR5, 3X M.2, PCIe 5.0, Front USB Type-C, WIFI6E, 2.5GbE LAN, EZ-Latch

GIGABYTE Z890 (ATX) Motherboard Specifications

CPU

• LGA1851 socket supports Intel® Core™ Ultra Processors

• L3 Cache varies depending on the CPU

Chipset

• Intel® Z890 Express Chipset

RAM

• Supports DDR5 up to 9200MT/s (OC)

• 4 DIMM slots, supporting up to 256GB

• Supports ECC (non-ECC mode) & XMP profiles

• CUDIMM memory module support

Integrated Graphics

• 1x USB4 Type-C (3840×2160 @ 144Hz)

• 1x DisplayPort 2.1 (3840×2160 @ 144Hz)

• Graphics support depends on CPU

Audio

• Realtek® Audio CODEC

• Supports up to 7.1 channels

Networking (LAN)

• Realtek® 2.5GbE LAN

Expansion Slots

• 1x PCIe 5.0 x16 (for GPU or NVMe SSD)

• 2x PCIe 4.0 x4

Storage

• 2x M.2 PCIe 5.0 x4

• 2x M.2 PCIe 4.0 x4 (one supports SATA)

• 4x SATA 6Gb/s

• RAID 0, 1, 5, 10 support for NVMe & SATA

USB Ports

• 1x USB4 Type-C (back panel)

• 1x USB 3.2 Gen 2 Type-A

• 7x USB 3.2 Gen 1

• 8x USB 2.0/1.1

Back Panel Ports

• USB4 Type-C, DisplayPort

• 1x RJ-45 (LAN), 3x Audio Jacks

• PS/2 (Keyboard/Mouse)

Additional Features

• Dual 8-pin ATX power connectors

• Q-Flash Plus, Smart Backup support

• Thunderbolt™ add-in card connectors

• Sensors for temperature, voltage, and fan speed

Supported Operating System

• Windows 11 (64-bit)

Form Factor & Design

• ATX, 30.5cm × 24.4cm
