AMD Ryzen 7 9800X3D 8 Cores- 16 Threads AM5 Processor

AMD Ryzen 7 9800X3D Desktop Processor

General Specifications

• Architecture: Zen 5, 4nm (CPU), 6nm (I/O Die) TSMC FinFET.
• Codename: Granite Ridge.
• Cores/Threads: 8 Cores / 16 Threads.
• Base Clock: 4.7 GHz.
• Max Boost Clock: Up to 5.2 GHz.
• Cache:
  • L1: 640 KB.
  • L2: 8 MB.
  • L3: 96 MB.
• TDP: 120W.
• Unlocked for Overclocking: Yes.

Performance Features

• AMD EXPO™ Memory Overclocking Technology: Yes.
• Precision Boost Overdrive: Yes.
• Curve Optimizer: Yes.
• CPU Boost Technology: Precision Boost 2.

Connectivity & Memory

• PCIe Version: PCIe® 5.0 with 28 lanes (24 usable).
• Native USB Ports:
  • USB 3.2 Gen 2 (10Gbps): 4 ports.
  • USB 2.0 (480Mbps): 1 port.
• Memory Type: DDR5.
• Channels: Dual-channel.
• Maximum Memory Capacity: 192GB.
• Memory Speed:
  • 2x1R: DDR5-5600.
  • 2x2R: DDR5-5600.
  • 4x1R: DDR5-3600.
  • 4x2R: DDR5-3600.
• ECC Support: Yes (requires motherboard support).

Graphics Capabilities

• Integrated Graphics Model: AMD Radeon™ Graphics.
• Graphics Core Count: 2.
• Frequency: 2200 MHz.
• USB Type-C® DisplayPort™ Alternate Mode: Yes.

Compatibility

• Socket: AM5.
• Supported Chipsets: A620, B650, B650E, B850, X670, X670E, X870, X870E, B840.
• OS Support:
  • Windows 11 (64-bit).
  • Windows 10 (64-bit).
  • RHEL x86 (64-bit).
  • Ubuntu x86 (64-bit).

Cooling & Thermal

• Recommended Cooler: Liquid cooling for optimal performance.
• Max Operating Temperature (Tjmax): 95°C.
• Thermal Solution (PIB): Not included.

Instruction Set & Features

• Instruction Set: x86-64.
• Extensions: AES, AMD-V, AVX, AVX2, AVX512, FMA3, MMX-plus, SHA, SSE4.1, SSE4.2, SSSE3, and more.

Use Case

• Segment: Enthusiast desktop.
• Market Availability: Global.
• Target Use: Gaming, productivity, and performance-heavy applications.
